Bellow & Expansion Joints

JV250001 – EPDM Expansion Bellows Joint

JV250001 expansion joint with EPDM tube helps to alleviate stress in potable water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections:20mm (3/4″) to 50mm (2″) • BSP Threaded Female Unions

Duty: Potable (Drinking) Water

Materials: EPDM Inner Tube & Cover • Galvanised Malleable Iron Fittings

Pressure Rating: Vac (500mm HG) to 16 Bar

Temperature Range: -10°C to 80°C (dependent on pressure)

JV250002 – EPDM Expansion Bellows Joint

The JV250002 expansion joint with EPDM tube helps to alleviate stress in HVAC and water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections:15mm (1/2″) to 80mm (3″) • BSP Threaded Female Unions

Duty: HVAC • Water

Materials: EPDM Inner Tube & Cover • Galvanised Iron Fittings

Pressure Rating: PN16

Temperature Range: -10°C to 100°C (dependent on pressure)

JV250005 – EPDM Expansion Bellows Joint

JV250005 expansion joint with EPDM tube helps to alleviate stress in potable water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN40 to DN300 • PN16 Flanged

Duty: Potable (Drinking) Water

Materials: EPDM Bellows • Galvanised Steel Flanges

Pressure Rating: 16 Bar

Temperature Range: -10°C to 100°C (dependent on pressure)

JV250004 – EPDM Expansion Bellows Joint – 130mm Length

JV250004 expansion joint with EPDM tube helps to alleviate stress in potable water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN300 • PN16 Flanged (PN10 on request)

Duty: Potable (Drinking) Water

Materials: EPDM Inner Tube & Cover • Galvanised Steel Flanges

Pressure Rating:Vac (500mm HG) to 16 Bar:

Temperature Range: -10°C to 90°C (dependent on pressure)

JV250011 – EPDM Expansion Bellows Joint

The JV250011 expansion joint with EPDM tube helps to alleviate stress in potable water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN600 PN10 Flange

Duty: HVAC • Water

Materials: EPDM Inner Tube & Cover • Galvanised Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-600mm: PN10 Rated

Temperature Range: -10°C to 100°C (dependent on pressure)

JV250003 – EPDM Expansion Bellows Joint – 130mm Length

The JV250003 expansion joint with EPDM tube helps to alleviate stress in potable water systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: HVAC • Water

Materials: EPDM Inner Tube & Cover • Galvanised Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -10°C to 100°C (dependent on pressure)

JV250012 – NBR Expansion Bellows Joint – Air & Oil Duty

The JV250012 expansion joint helps to alleviate stress in air and oil systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 PN10 Flange

Duty: Air • Oil

Materials: NBR Inner Tube & Cover • Galvanised Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm: PN10 Rated

Temperature Range: -10°C to 80°C (dependent on pressure)

JV250013 – NBR Expansion Bellows Joint – 130mm Length – Air & Oil Duty

JV250013 expansion joint helps to alleviate stress in air and oil systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 PN10 Flange

Duty: Air • Oil

Materials: NBR Inner Tube & Cover • Galvanised Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm: PN10 Rated

Temperature Range: -10°C to 80°C (dependent on pressure)

JV250021 – Metal Axial Expansion Joint – Stainless Steel Bellows

The JV240021 is a general-purpose metal axial expansion joint helps to alleviate stress in systems by absorbing longitudinal expansion and compression in pipework..

Size & Connections: 15mm (1/2″) to 50mm (2″) • BSP Threaded

Duty: General-Purpose

Materials: Stainless Steel Bellows • Steel Ends

Pressure Rating: PN16 Rated

Temperature Range: -20°C to 300°C (dependent on pressure)

JV250022 – Metal Axial Expansion Joint – Stainless Steel Bellows

The JV240022 is a general-purpose metal axial expansion joint helps to alleviate stress in systems by absorbing longitudinal expansion and compression in pipework..

Size & Connections: DN25 (1″) to DN250 (10″) • Butt Weld Ends

Duty: General-Purpose

Materials: Stainless Steel Bellows • Steel Ends

Pressure Rating: PN16 Rated

Temperature Range: -20°C to 300°C (dependent on pressure)

JV250023 – Metal Axial Expansion Joint – Stainless Steel Bellows

The JV240023 is a general-purpose metal axial expansion joint helps to alleviate stress in systems by absorbing longitudinal expansion and compression in pipework..

Size & Connections: DN15 to DN250 • PN16 Flanged

Duty: General-Purpose

Materials: Stainless Steel Bellows • Steel Ends

Pressure Rating: PN16 Rated

Temperature Range: -20°C to 300°C (dependent on pressure)

JV250014 – EPDM High-Performance Expansion Bellows Joint

JV240014 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Water • Hot Water with Salt Solutions • Chlorine solutions • Esters • Ketones

Materials: EPDM Inner Tube & Cover • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -35°C to 90°C (dependent on pressure)

JV250015 – ACS Approved EPDM High-Performance Expansion Bellows Joint

JV240015 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Potable (Drinking) Water

Materials: EPDM Inner Tube & Cover • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -25°C to 90°C (dependent on pressure)

JV250016 – High-Temperature EPDM Expansion Bellows Joint

JV240016 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Hot Water • Steam • Heating Systems

Materials: HT EPDM Inner Tube & Cover • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -35°C to 130°C (dependent on pressure)

JV250017 – Epichlorohydrin (ECO) High-Performance Expansion Bellows Joint

JV240017 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Oils • Gasses • Hydrocarbons

Materials: Epichlorohydrin (ECO) Inner Tube & Cover • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -25°C to 90°C (dependent on pressure)

JV250018 – Chlorosulfonated-Polyethylene (CSM) High-Performance Expansion Bellows Joint

JV240018 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Chemicals • Strong & Concentrated Acids • Solvents

Materials: Chlorosulfonated-Polyethylene (CSM) Inner Tube • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -25°C to 90°C (dependent on pressure)

JV250019 – Food Grade White NBR High-Performance Expansion Bellows Joint

JV240019 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: Food • Beverages • Fats • Oils

Materials: Food Grade White NBR Inner Tube • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -25°C to 90°C (dependent on pressure)

JV250020 – FKM High-Performance Expansion Bellows Joint

JV240020 expansion joint helps to alleviate stress in systems by absorbing vibration, noise, thermal expansion, compression, lateral and angular movements in the pipework.

Size & Connections: DN32 to DN150 PN16 Flange • DN200 to DN300 PN10 Flange

Duty: High-Temperature Chemicals, Hydrocarbons & Solvents

Materials: FKM Inner Tube & Cover • Zinc Plated Steel Flanges

Pressure Rating: 32mm-150mm: PN16 Rated • 200mm-300mm: PN10 Rated

Temperature Range: -20°C to 150°C (dependent on pressure)
